Need info on a Holset HE-351cw Please Help
1.0 BAR
Joined: Mar 2006
Posts: 279
Re: Need info on a Holset HE-351cw Please Help
More pictures of the Ranger are available here.
Mods on the ranger:
- 2.3T swapped from my '86 XR4Ti parts car
- 40bob.com flipped-style Ranger log manifold
- Holset HY35W
- Volvo 740 intercooler
- big loud ricer BOV from ebay
- Explorer 4.0 radiator (w/o any fans
)
- SSautocrap 35/38mm wastegate
- boostvalve.com boost controller
- 3" exhaust with a magnaflow can (all piping scrounged from the exhaust shop dumpster
)
- T5 trans from a TurboCoupe
- Megasquirt V2.2 for fueling (also controls the TFI ignition)
Yah, the Holset is kinda laggy on the Ranger. It used to have a stock T3, but then ******** Nick (the owner) was trying to clock teh compressor housing and dropped it on the wheel... so we ended up putting a smaller wheel and housing on it from a 2.2 or 2.5L turbododge - that thing spooled really nice... wheelspin in 3rd gear (and this is not a wrong-wheel-drive vehicle...) but we determined it was just a tad inneficient at 18 psi, so on went the Holset. Nick's plan is to tow some trailers and stuff with this, so the big compressor is definitely going to help - he won't just be spooling constantly and blowing hot air.
Oh yeah... as for that radiator... the Saab 900 one is almost a bolt-in affair and it's shorter, so there's room to run IC pipes over the top:
I bought this radiator brand new on eghay for $75.
Fits really nice behind the NPR intercooler...
Whoa, who's your friend? Hal, Mike Lough, Stackz, etc?
My 16V conversion *should* be running in a few weeks.
I should really stop hijacking threads...
Colin
Mods on the ranger:
- 2.3T swapped from my '86 XR4Ti parts car
- 40bob.com flipped-style Ranger log manifold
- Holset HY35W
- Volvo 740 intercooler
- big loud ricer BOV from ebay
- Explorer 4.0 radiator (w/o any fans
)- SSautocrap 35/38mm wastegate
- boostvalve.com boost controller
- 3" exhaust with a magnaflow can (all piping scrounged from the exhaust shop dumpster
)- T5 trans from a TurboCoupe
- Megasquirt V2.2 for fueling (also controls the TFI ignition)
Originally Posted by AbaZ
lol, thats funny you say that I was just reminding my buddy mike the other day how much that radiator costs when he broke the neck off of it. I think it was like 340 dollars special order from Europe
But ya, I'm trying to talk Mike actually into to turboing his 2.3l Ford Ranger, and I saw those pics and got a mild stiffy, especially with the fatty holset on there, Probably a bit laggy eh?
But ya, I'm trying to talk Mike actually into to turboing his 2.3l Ford Ranger, and I saw those pics and got a mild stiffy, especially with the fatty holset on there, Probably a bit laggy eh?
Oh yeah... as for that radiator... the Saab 900 one is almost a bolt-in affair and it's shorter, so there's room to run IC pipes over the top:
I bought this radiator brand new on eghay for $75.
Fits really nice behind the NPR intercooler...
Originally Posted by Joseph Davis
My best friend has a Volvo head on his XR4ti. It's still waiting on Autronic and a fuel system.
My 16V conversion *should* be running in a few weeks. I should really stop hijacking threads...
Colin
0.0 BAR
Joined: Feb 2003
Posts: 0
Re: Need info on a Holset HE-351cw Please Help
He was monitoring the 16v-2300 list on yahoorgroups once a month, more or less, for a couple. He was alwso talking on the phone to antoher guy named Dave in TX (his name is Dave).
1.0 BAR
Joined: Apr 2004
Posts: 240
Re: Need info on a Holset HE-351cw Please Help
HE351CW specs... straight from Holset... I emailed them last night.
"60mm inducer / 85mm backface. The tubine housing is a 9cm^2.
Turbine wheel is a 65mm backface / 58mm inducer. "
"60mm inducer / 85mm backface. The tubine housing is a 9cm^2.
Turbine wheel is a 65mm backface / 58mm inducer. "
