88 Fiero GT. Engine swap. Custom turbo build.
#23
Re: 88 Fiero GT. Engine swap. Custom turbo build.
I wantede to hate this pile of ---- as I SAW NO ------- POPRN IN THE INTRO... But I really dig the car....
And your cat but there is no Ch33ZeBurg3r in Teh Pan. L4wlZ
Now dont be a ****** and post some **** (and none of that gay ----.
Welcome, nice ride... Even if it is a gay *** Fiero, it could be worse, I guess.... it could be a Ford... Or an Accord
LOL
And your cat but there is no Ch33ZeBurg3r in Teh Pan. L4wlZ
Now dont be a ****** and post some **** (and none of that gay ----.
Welcome, nice ride... Even if it is a gay *** Fiero, it could be worse, I guess.... it could be a Ford... Or an Accord
LOL
#24
Re: 88 Fiero GT. Engine swap. Custom turbo build.
By small intercooler, I meant the bike rad you refered to earlier as teh heat exhanger. I've never seen a street bike with a particularly large radiator, but I do know of several air-water setups that have large heat exchangers that still lead to heatsoak if you do more than a few pulls at a time. Maybe you don't look at your IAT's much? Anyways, max capacity is different from continuous capacity. For example, a particular bone-stock B16 held 560whp for several dyno pulls and a few track runs, but still blew up later (only making 300whp blown ).
As for the divided housings, it would be like a true dual exhaust if you know much about V8's and x-overs and crap.
The dirty explaination:
Turbos require high manifold pressure, which hurts exhaust scavenging; exhaust pulses can hurt further if the pressure wave hits a valve that's starting to open, or one that's at the overlap point. Dividing the cylinders evenly reduces this considerably, especially with more power/rpm. The way it helps spool the turbo is the reduced pressure needed. Each exhaust pulse has to fill half the volume of piping before it 'acts' upon the turbine wheel. You can either use a single WG (divided all the way to the valve), or two WG's if that makes it simpler. Since there's up to a 3:1 pressure differential between manifold & downpipe/dumppipe, the gases do not revert back into the other half of the divided manifold. You then increase the housing size, which still results in more power AND better response/spool.
As for GT knowledge, you are lacking. A GT35 signifies roughly a T3 turbine & CHRA with a T4 compressor. So you're essentially running a T3 turbine wheel in a T4 exhaust housing. Although the housing does play a big role, the role of turbine wheel trumps that. You won't add much HP capacaity with a larger housing when you keep the same turbine wheel. Now for turbo sizing for displacement - 500whp with gasoline with produce roughly the same amount of exhaust gases, wether its on a 2.0L motor or a 4.0L motor. You do generally upsize the turbo on a bigger motor, but that's just due to the smaller cylinders burning the mixture faster, making a little more power per CFM.
Case and point, a 1.8L GSR with a GT35R w/ undivided .82AR T3 housing. 17psi with 93 octane netted ~420whp. Moving the powerband around for a 3.4L motor puts spool at ~3500rpm, and same NA exhaust flow at your 5k vs his 8.4k. Look where he made 420whp, then look where your engine makes the best power... (It also shows that 'small' housing can make 605whp, 2nd link shows 650whp) If anything, you should have just gone with an overall larger turbo like a GT4088R, or even a Borg-Warner turbo.
http://forums.evans-tuning.com/viewt...hp?f=27&t=4808
http://forums.evans-tuning.com/viewt...hp?f=27&t=4656
ATP turbo's pages help lots with info, since they offer so many options & examples:
http://www.atpturbo.com/Merchant2/me...egory_Code=GRT
BTW, all the 'n00b' ---- posted is good. Basicly we accept you, but there's still the 90-day probationary period in case you wave teh homo flag or something. :P
As for the divided housings, it would be like a true dual exhaust if you know much about V8's and x-overs and crap.
The dirty explaination:
Turbos require high manifold pressure, which hurts exhaust scavenging; exhaust pulses can hurt further if the pressure wave hits a valve that's starting to open, or one that's at the overlap point. Dividing the cylinders evenly reduces this considerably, especially with more power/rpm. The way it helps spool the turbo is the reduced pressure needed. Each exhaust pulse has to fill half the volume of piping before it 'acts' upon the turbine wheel. You can either use a single WG (divided all the way to the valve), or two WG's if that makes it simpler. Since there's up to a 3:1 pressure differential between manifold & downpipe/dumppipe, the gases do not revert back into the other half of the divided manifold. You then increase the housing size, which still results in more power AND better response/spool.
As for GT knowledge, you are lacking. A GT35 signifies roughly a T3 turbine & CHRA with a T4 compressor. So you're essentially running a T3 turbine wheel in a T4 exhaust housing. Although the housing does play a big role, the role of turbine wheel trumps that. You won't add much HP capacaity with a larger housing when you keep the same turbine wheel. Now for turbo sizing for displacement - 500whp with gasoline with produce roughly the same amount of exhaust gases, wether its on a 2.0L motor or a 4.0L motor. You do generally upsize the turbo on a bigger motor, but that's just due to the smaller cylinders burning the mixture faster, making a little more power per CFM.
Case and point, a 1.8L GSR with a GT35R w/ undivided .82AR T3 housing. 17psi with 93 octane netted ~420whp. Moving the powerband around for a 3.4L motor puts spool at ~3500rpm, and same NA exhaust flow at your 5k vs his 8.4k. Look where he made 420whp, then look where your engine makes the best power... (It also shows that 'small' housing can make 605whp, 2nd link shows 650whp) If anything, you should have just gone with an overall larger turbo like a GT4088R, or even a Borg-Warner turbo.
http://forums.evans-tuning.com/viewt...hp?f=27&t=4808
http://forums.evans-tuning.com/viewt...hp?f=27&t=4656
ATP turbo's pages help lots with info, since they offer so many options & examples:
http://www.atpturbo.com/Merchant2/me...egory_Code=GRT
BTW, all the 'n00b' ---- posted is good. Basicly we accept you, but there's still the 90-day probationary period in case you wave teh homo flag or something. :P
#25
Re: 88 Fiero GT. Engine swap. Custom turbo build.
Good write up, but stop calling a 60mm turbo a huge turbo, it is on the small end of mid sized turbo's, that and 3.4L's on a T3 hotside...
Edit, holy ---- lots was posted in the time i pushed reply.
Edit, holy ---- lots was posted in the time i pushed reply.
#26
Re: 88 Fiero GT. Engine swap. Custom turbo build.
Ya I would have went for at least a 67 MM and T4 1.01 hotside
My 2.2L PIle spools the ---- out of a S cover PT6176 with T4 hotside...... This thing would have absoilutely no problem... Even wiith the gay rev limited top end...
My 2.2L PIle spools the ---- out of a S cover PT6176 with T4 hotside...... This thing would have absoilutely no problem... Even wiith the gay rev limited top end...
#27
Guest
Posts: n/a
Re: 88 Fiero GT. Engine swap. Custom turbo build.
Nice work man. I always kinda had a thing for that year of fiero, but it was kinda like the crush I had for the dorky girl in class with the nice **** and and ***. I always wanted to see what it was like, but never wanted my friends to find out.
#28
Re: 88 Fiero GT. Engine swap. Custom turbo build.
Originally Posted by AaronZ34
I'm not sure if that's a good thing or not....So....I'll just keep my mouth shut....
#29
Re: 88 Fiero GT. Engine swap. Custom turbo build.
Originally Posted by bigdaddyvtec
I wantede to hate this pile of ---- as I SAW NO ------- POPRN IN THE INTRO... But I really dig the car....
And your cat but there is no Ch33ZeBurg3r in Teh Pan. L4wlZ
Now dont be a ****** and post some **** (and none of that gay ----.
Welcome, nice ride... Even if it is a gay *** Fiero, it could be worse, I guess.... it could be a Ford... Or an Accord
And your cat but there is no Ch33ZeBurg3r in Teh Pan. L4wlZ
Now dont be a ****** and post some **** (and none of that gay ----.
Welcome, nice ride... Even if it is a gay *** Fiero, it could be worse, I guess.... it could be a Ford... Or an Accord
Or a Honda in general....It's not like it's much different from a Honda, just a cheap econobox. Just mine's RWD, and actually looks good
Originally Posted by HiProfile
By small intercooler, I meant the bike rad you refered to earlier as teh heat exhanger. I've never seen a street bike with a particularly large radiator, but I do know of several air-water setups that have large heat exchangers that still lead to heatsoak if you do more than a few pulls at a time. Maybe you don't look at your IAT's much? Anyways, max capacity is different from continuous capacity. For example, a particular bone-stock B16 held 560whp for several dyno pulls and a few track runs, but still blew up later (only making 300whp blown ).
As for the divided housings, it would be like a true dual exhaust if you know much about V8's and x-overs and crap.
The dirty explaination:
Turbos require high manifold pressure, which hurts exhaust scavenging; exhaust pulses can hurt further if the pressure wave hits a valve that's starting to open, or one that's at the overlap point. Dividing the cylinders evenly reduces this considerably, especially with more power/rpm. The way it helps spool the turbo is the reduced pressure needed. Each exhaust pulse has to fill half the volume of piping before it 'acts' upon the turbine wheel. You can either use a single WG (divided all the way to the valve), or two WG's if that makes it simpler. Since there's up to a 3:1 pressure differential between manifold & downpipe/dumppipe, the gases do not revert back into the other half of the divided manifold. You then increase the housing size, which still results in more power AND better response/spool.
As for GT knowledge, you are lacking. A GT35 signifies roughly a T3 turbine & CHRA with a T4 compressor. So you're essentially running a T3 turbine wheel in a T4 exhaust housing. Although the housing does play a big role, the role of turbine wheel trumps that. You won't add much HP capacaity with a larger housing when you keep the same turbine wheel. Now for turbo sizing for displacement - 500whp with gasoline with produce roughly the same amount of exhaust gases, wether its on a 2.0L motor or a 4.0L motor. You do generally upsize the turbo on a bigger motor, but that's just due to the smaller cylinders burning the mixture faster, making a little more power per CFM.
Case and point, a 1.8L GSR with a GT35R w/ undivided .82AR T3 housing. 17psi with 93 octane netted ~420whp. Moving the powerband around for a 3.4L motor puts spool at ~3500rpm, and same NA exhaust flow at your 5k vs his 8.4k. Look where he made 420whp, then look where your engine makes the best power... (It also shows that 'small' housing can make 605whp, 2nd link shows 650whp) If anything, you should have just gone with an overall larger turbo like a GT4088R, or even a Borg-Warner turbo.
http://forums.evans-tuning.com/viewt...hp?f=27&t=4808
http://forums.evans-tuning.com/viewt...hp?f=27&t=4656
ATP turbo's pages help lots with info, since they offer so many options & examples:
http://www.atpturbo.com/Merchant2/me...egory_Code=GRT
BTW, all the 'n00b' ---- posted is good. Basicly we accept you, but there's still the 90-day probationary period in case you wave teh homo flag or something. :P
As for the divided housings, it would be like a true dual exhaust if you know much about V8's and x-overs and crap.
The dirty explaination:
Turbos require high manifold pressure, which hurts exhaust scavenging; exhaust pulses can hurt further if the pressure wave hits a valve that's starting to open, or one that's at the overlap point. Dividing the cylinders evenly reduces this considerably, especially with more power/rpm. The way it helps spool the turbo is the reduced pressure needed. Each exhaust pulse has to fill half the volume of piping before it 'acts' upon the turbine wheel. You can either use a single WG (divided all the way to the valve), or two WG's if that makes it simpler. Since there's up to a 3:1 pressure differential between manifold & downpipe/dumppipe, the gases do not revert back into the other half of the divided manifold. You then increase the housing size, which still results in more power AND better response/spool.
As for GT knowledge, you are lacking. A GT35 signifies roughly a T3 turbine & CHRA with a T4 compressor. So you're essentially running a T3 turbine wheel in a T4 exhaust housing. Although the housing does play a big role, the role of turbine wheel trumps that. You won't add much HP capacaity with a larger housing when you keep the same turbine wheel. Now for turbo sizing for displacement - 500whp with gasoline with produce roughly the same amount of exhaust gases, wether its on a 2.0L motor or a 4.0L motor. You do generally upsize the turbo on a bigger motor, but that's just due to the smaller cylinders burning the mixture faster, making a little more power per CFM.
Case and point, a 1.8L GSR with a GT35R w/ undivided .82AR T3 housing. 17psi with 93 octane netted ~420whp. Moving the powerband around for a 3.4L motor puts spool at ~3500rpm, and same NA exhaust flow at your 5k vs his 8.4k. Look where he made 420whp, then look where your engine makes the best power... (It also shows that 'small' housing can make 605whp, 2nd link shows 650whp) If anything, you should have just gone with an overall larger turbo like a GT4088R, or even a Borg-Warner turbo.
http://forums.evans-tuning.com/viewt...hp?f=27&t=4808
http://forums.evans-tuning.com/viewt...hp?f=27&t=4656
ATP turbo's pages help lots with info, since they offer so many options & examples:
http://www.atpturbo.com/Merchant2/me...egory_Code=GRT
BTW, all the 'n00b' ---- posted is good. Basicly we accept you, but there's still the 90-day probationary period in case you wave teh homo flag or something. :P
I know my way around a V8
Interesting about the divided housings.
I chose the 35 for a reason, and spent a lot of time in compressor maps. At this altitude, it's on the big side of what I need (Which partially explains it not coming on until 3500rpm). I definitely don't want bigger, however don't really want to go smaller either. However using current technology (Split housings, variable vanes, etc), I could probably pick up a bit of power int he midrange. But it wouldn't be worth the added cost of doing it right now.
As for the huge numbers that guy's 1.8 is putting down, that's all wonderful and all, but it isn't practical for me. 600rwhp, and I'm pretty sure I'd be chucking rods (Stock short block). Plus, the car is already a handful at 417rwhp. I've driven plenty of 600hp cars, but a 600hp Fiero is different, and it isn't just the weight (It still weighs 2800).
Thanks for the info. I stand by that I sized my turbo correctly, and at sea level it'd come on much quicker (All of my flow calcs were done assuming ambient temp/pres). But if I were interested in doing it over now, I thing I would go with a T3 divided housing. I'd actually go with twins, but same idea.
Regarding my sexual preferences, see pictures above (Minus the last one).
Originally Posted by dvst8r
Good write up, but stop calling a 60mm turbo a huge turbo, it is on the small end of mid sized turbo's, that and 3.4L's on a T3 hotside...
Edit, holy ---- lots was posted in the time i pushed reply.
Edit, holy ---- lots was posted in the time i pushed reply.
Originally Posted by bigdaddyvtec
Ya I would have went for at least a 67 MM and T4 1.01 hotside
My 2.2L PIle spools the ---- out of a S cover PT6176 with T4 hotside...... This thing would have absoilutely no problem... Even wiith the gay rev limited top end...
My 2.2L PIle spools the ---- out of a S cover PT6176 with T4 hotside...... This thing would have absoilutely no problem... Even wiith the gay rev limited top end...
#30
Re: 88 Fiero GT. Engine swap. Custom turbo build.
Originally Posted by carkrazed2005
Nice work man. I always kinda had a thing for that year of fiero, but it was kinda like the crush I had for the dorky girl in class with the nice **** and and ***. I always wanted to see what it was like, but never wanted my friends to find out.
Although it has a bad reputation, I've never had more fun driving a car in my life (And I've driven some pimpass cars). Plus, it's not FWD, hooks up like it's AWD, and it's very easy to get it fast.
Originally Posted by crxvtec91
Thats a good thing. I have not seen a better intro post in a while. The same old dirty D-series gets a little old sometimes.
