ok, i have a 91 civic Si w/b16a1 and converted into OBD1 p28 ecu...the problem is why can't i hack into the ecu where that plug with the 2 wires so i can see what codes my car is throwing?? when i was using the OBD0 JDM b16 ecu it had an LED light on it so it wasn't no big deal...did anybody had the same problem as i did...need help ASAP........



Look at the pinouts for the ECU. Just splice the wires, no big deal.



Most conversion harnesses come with 2 wire you can put on a switch to enable it.



Im with the same problem, how can i hack into the ecu so i can see what codes my car is throwing. And where is, that plug with the 2 wires



i know in my xenocron harness its the orange wire and the blue wire u need to connect to flash the check engine light. i have an obd1 converted 90 teg



see, the reason why i'm so confused is b/c my conversion harness from rywire.com looks like this....all nothing but gray except the vtec and o2 wires...



if someone could, try finding me a site for this situation or post up some pics of yours since i'm not an expert on this stuff...



i found this





oh sorry!, this pic is a HOW TO see wich codes are throwing the ECU with a led
