Stuck at step 40. MS-II V3.0

Old 12-17-2008, 11:44 PM
  #1
0.5 BAR
Thread Starter

Join Date: Jan 2007
Posts: 53
Default Stuck at step 40. MS-II V3.0

I've reached step 40, but can't get any further. I'm assembling a MS-II V3.0 and everything has gone smooth so far. It has passed all tests to this point. I'm pretty sure my problem is a lack of PC knowledge.

The files I've downloaded so far are:

ms2dl200_setup
Monitor_v2.888a.abs
megasquirt-II.ini.2.8

When I install and run the first program. It says this:

For pre-Extra MS-II:
1) Short the "B/LD" jumper on the MS-II board.
2) Power cycle MS-II.
3) File->Open.

I am choosing a file on the desktop called "Monitor_v2.888a.abs". Then I get a box that says the following:

MegaSquirt Download 2.00

Reading C:/Documents and Settings/Innovate Tuner/Desktop/Monitor_v2.888a.abs.s19:
Detected MS-II (HCS12) code.
Entry point: 0x0000
Code range : 0x4000-0x3db3e0
File read successfully.

Download failed:
Could not open comm port 1.
Exception caught: 2
MegaSquirt Download 2.00

Reading C:/Documents and Settings/Innovate Tuner/Desktop/Monitor_v2.888a.abs.s19:
Detected MS-II (HCS12) code.
Entry point: 0x0000
Code range : 0x4000-0x3db3e0
File read successfully.

Download failed:
Could not open comm port 1.
Exception caught: 2



I've gone into device manager and there is one port that says "USB Serial Port (COM1)". In port settings I have the following settings:

Bits per second: 115200
Data bits: 8
Parity: None
Stop bits: 1
Flow control: None

Here's what's in front of me


Anybody know what's going on here?

wrinkledmr2 is offline
Old 12-18-2008, 10:06 AM
  #2
3.0 BAR

Hitchhikkr's Avatar

Join Date: Oct 2006
Posts: 2,330
Default Re: Stuck at step 40. MS-II V3.0

Serial to USB issues perhaps? What usb adapter is that?
Hitchhikkr is offline
Old 12-18-2008, 10:28 AM
  #3
0.5 BAR
Thread Starter

Join Date: Jan 2007
Posts: 53
Default Re: Stuck at step 40. MS-II V3.0

Everything came from diyauottune. It has to be something with the PC but I'm a retard when it comes to that stuff. :1

I own two Macs because they WORK!
wrinkledmr2 is offline
Old 12-18-2008, 02:12 PM
  #4
0.0 BAR

Join Date: Apr 2006
Posts: 0
Default Re: Stuck at step 40. MS-II V3.0

get ms1 v2.2 instructions and go to your communications port ---- for windows it tells you how to look for the port with hyperterminal (start > progs > accys > entertainment > hyperterminal OMG HT)
Smith-02 is offline
Old 12-18-2008, 08:22 PM
  #5
0.0 BAR

Join Date: Oct 2008
Posts: 1
Default Re: Stuck at step 40. MS-II V3.0

You need to configure your COM port correctly...

Bits per sec: 9600
Data bits: 8
Parity: none
Stop bit: 1
Flow control: none
sikdogg is offline
Old 12-18-2008, 08:24 PM
  #6
0.0 BAR

Join Date: Apr 2006
Posts: 0
Default Re: Stuck at step 40. MS-II V3.0

Originally Posted by sikdogg
You need to configure your COM port correctly...

Bits per sec: 9600
Data bits: 8
Parity: none
Stop bit: 1
Flow control: none
yeah thats it
Smith-02 is offline
Old 12-18-2008, 11:04 PM
  #7
0.5 BAR
Thread Starter

Join Date: Jan 2007
Posts: 53
Default Re: Stuck at step 40. MS-II V3.0

Unless I missed something somewhere those settings are for MS-I. MS-II V3.0 uses 115200 bits per second.
wrinkledmr2 is offline
Old 12-19-2008, 02:42 AM
  #8
0.0 BAR

Join Date: Apr 2006
Posts: 0
Default Re: Stuck at step 40. MS-II V3.0

if you know the answer then go figure it out
Smith-02 is offline
Old 12-19-2008, 03:16 AM
  #10
0.0 BAR

Join Date: Apr 2006
Posts: 0
Default Re: Stuck at step 40. MS-II V3.0

Originally Posted by jagojon3
There goes dumbplex talking like he knows anything again
i don't see you bothering to add any tech to the thread, **********
Smith-02 is offline
